RELIANCE ELECTRIC DRIVE AC MD60 3HP 2.2KW 7.5AMP 3PH 480VAC 50/60HZ

New Surplus Factory Package
SKU: 22MD1
3 Year Warranty

1-919-372-8413 | 1-800-991-7026

sales@axcontrol.com

Request Quote
New Surplus AX Control Package
SKU: 22MD2
3 Year Warranty

1-919-372-8413 | 1-800-991-7026

sales@axcontrol.com

Request Quote
Reconditioned
SKU: 22MD3
3 Year Warranty

1-919-372-8413 | 1-800-991-7026

sales@axcontrol.com

Request Quote
Repair
$423
SKU: 22MD4
3 Year Warranty

1-919-372-8413 | 1-800-991-7026

sales@axcontrol.com

* Learn More About Product Conditions
* Posted pricing available for website purchases only.

Product Conditions

New Surplus Factory Package: A completely unused product that is in the original factory package. The package may have been opened for the purpose of pictures, but the product has never been used or installed.

New Surplus AX Control Package: A completely unused product that has been removed from the original factory package. Often due to shelf wear or previous shipping, the factory package is not adequate and must be replaced with an ideal AX Control product package.

Reconditioned: All products that qualify as reconditioned have completed AX Control's thorough and detailed QA process and meet the requirements of excellent working condition and excellent cosmetic condition.

Product Description

6MDDN-6P0101 is a Reliance Electric 460V, 50/60 Hz, 3-phase drive that is part of the MD60 drive series. This drive has 2.2 kW, a horsepower rating of 3.0, and an output current of 6.0 A. The frame size is B. There are a number of parameters on the MD60 drive. Parameter A069 is the Internal Frequency. The default is 0.0 Hz and the range is 0.0 to 240 Hz. Parameter A070 through A073 are Preset Frequencies 0-3. The default is 0.0 Hz and the range is 0.0 to 240.0 Hz. Parameter A078 is the Jog Frequency. The default is 10.0 Hz and the range is 0.0 to the maximum frequency. Parameter A079 is the Jog Acceleration/Deceleration. The default is 10 seconds and the range is 0.1 to 600.0 seconds. Parameter A080 is the DC Brake time. The default is 0.0 seconds. The range is 0.0 to 90.0 seconds. Parameter A081 is the DC Brake Level. The default is the amps x 0.5 and the range is 0.0 to the drive amps x 1.8. Parameter A082 is the DB Registor Select. The default is 0 (Disabled) and the range is 0 (Disabled), 1 (Reliance Electric Standard Resistor at 5% duty cycle), 2 No Protection at 100% duty cycle), and 3 to 99 (Duty Cycle Limited at 3% to 99% duty cycle). Parameter A083 is the S Curve %. The range is 0 to 100% and the default is 0% (disabled). Parameter A088 is the Maximum Voltage.

6MDDN-6P0101 Technical Specifications

Manufacturer Reliance Electric
Series MD60
Part Number 6MDDN-6P0101
HP 3 HP
Input Voltage 480 VAC
Enclosure NEMA 1 or Chassis
Hz 50/60Hz
kW 2.2kW
Filter/No Filter Not Filtered
Labeling UL Listed, IEC Certified

Frequently Asked Questions about 6MDDN-6P0101

What frame size does the MD60 6MDDN-6P0101 drive have?
The 6MDDN-6P0101 drive has a B frame size.
What output current drive rating does the 6MDDN-6P0101 have?
The reliance MD60 6MDDN-6P0101 has a 6.0A output current drive rating.
Is it okay to put my 6MDDN-6P0101 drive next to a window?
It is important that your MD60 Reliance Electric 6MDDN-6P0101 drive is protected from direct sunlight while operating so it is best to not put a 6MDDN-6P0101 drive next to a window or outdoors.
What is the shipping weight for a 6MDDN-6P0101?
Because a 6MDDN-6P0101 has a B frame size, a MD60 Reliance Electric 6MDDN-6P0101 has a shipping weight of 2.2kg or 4.9lbs.
What phase is a 6MDDN-6P0101?
The MD60 6MDDN-6P0101 is a 3 phase drive.
