6MDDN-017102

About the 6MDDN-017102

6MDDN-017102 is a 380-480 VAC 3-phase input, 0-460 V 3-phase output MD65 drive that is manufactured by Reliance Electric. This drive outputs 7.5 kW (10.0 HP) and 17.0 amps. The input voltage range is 340-528, the input kVA is 16.8, and the input amps are 18.4. The branch circuit protection is 30 for the fuses and 30 for the circuit breaker. The power dissipation is 200 watts. If you would like a price quote, click on the “Request a Quote” button on this page.

The drive has a number of performance features. The adjustable current limit is 10% - 150%. The operator interface module is drive mounted. The display lines support a 4-character LED display. There are eight programmable preset speeds. There is one analog output at 0-10 VDC or 4-20 mA. The drive supports auto restart. The frequency avoidance is one band. The fault memory is three deep. There are four configurable digital logic inputs. The drive als0 has a number of protective features. The power loss ride through is 500 milliseconds. The undervoltage level depends on the voltage class (240, 480, or 575). The ground fault is phase-to-ground on the drive output. The output short circuit is phase-to-phase on the drive output. The overtemperature feature is a heatsink monitor. The output voltage is on the DC bus. The drive overloads at a drive rating of 150% for one minute. The overcurrent feature is associated with the hardware overcurrent circuit and the software overcurrent fault. The agency certifications is UL, cUL, CE, and C-Tick
