About the 802275-41R
The 802275-41R module is a surge suppressor resistor assembly that was developed and manufactured by Reliance Electric to be used in the various machines that they produced. The 802275-41R resistor assembly continues to be kept within AX Control’s stock, despite the fact that it is no longer available new from the original manufacturer, Reliance Electric, or any of the other manufacturers who also produced this product, those manufacturers being Asea Brown Boveri and Baldor Reliance.
The 802275-41R resistor assembly is made up of many different resistors, as is suggested by the product’s name. There are six large wire wound resistors that make up almost the entirety of the 802275-41R resistor assembly. Next to these wire wound resistors, you will find two screw terminals for each resistor. In addition to that, these large resistors are connected to the outside of the 802275-41R resistor assembly, which are metal carriers. These metal carriers have flange mounting pieces, which make it easy to set up within a facility.
Upon installation, be sure that you have enough space for the 802275-41R resistor assembly, since it is a large device. Also, make sure that you give the 802275-41R resistor assembly and the area in which you are planning to install it a thorough cleaning. The area must be free of any debris, dirt, or dust. Failure to maintain a clean 802275-41R resistor assembly and its environment can result in malfunctioning hardware.
The 802275-41R resistor assembly has a total approximate weight of 1.30 lbs. or 0.59 kg., without including any of the packaging materials that AX Control uses to furnish the many packages that we ship out.
