1250HP Thyristor Assembly

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a 86466-91RC to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 86466-91RC
  • SKU: 8646691RCRE
  • Manufacturer: Reliance Electric
  • Series: Rectifiers & Misc.

Product Description

86466-91RC 1250HP Thyristor Assembly

The 86466-91RC is a Reliance Electric Thyristor Assembly for use within the company’s drives and their auxiliary systems.  Reliance thyristors like the 86466-91RC are no longer manufactured by the company but can be purchased from AX Control as reconditioned units or as never-used liquidated surplus parts.  Reliance parts were marketed and sold under the company name but were also sold under the manufacturing names of Baldor-Reliance and ABB.

The 86466-91RC is designed from two heat sink stacks connected together using bolts.  In the air gap between these heat sinks, there is an SCR diode mounted to the interior walls of the heat sinks.  This component is surface-wired to other components that are mounted within a hollow carrier connected to the base of one of the heat sinks.   Components here include transformers, terminal pins, resistors, and capacitors.

Thyristor assemblies function as four-layered semiconductor rectifiers where the flow of current between two electrodes (an anode and a cathode) is triggered by a third electrode (a gate.)

For a more complete description of the 86466-91RC, including information regarding installation and handling, please refer to technical support products originally provided to users by Reliance Electric.  This includes data sheets, product manuals, and user guides.

AX Control is a leading provider of obsolete industrial automation parts from GE, Fuji, Parker, Eurotherm, and many other manufacturers.  If you need a part quickly, ask our team about expedited shipping.   If you are local to the central North Carolina/RTP area, we are happy to work with your personal courier service to provide an even quicker turnaround.




Repair Services For 86466-91RC

Type Lead Time Price Action
Repair Service 1-2 weeks $516

Our highly skilled technicians can repair your 86466-91RC. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More

86466-91RC Manuals, White Papers, Data Sheets, and Troubleshooting
