This 86475-10R Rectifier Stack was manufactured for Reliance Electric's MaxPak Plus and FlexPak Plus Drive Systems Series.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a 86475-10R to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 86475-10R
  • SKU: 8647510RRE
  • Manufacturer: Reliance Electric
  • Series: Rectifiers & Misc.

86475-10R Technical Specifications

OEM Reliance Electric
Series Rectifiers & Misc.
Functional Description 86475-10R Rectifier Stack
Functional Part Number 86475-10R
Electric Potential 230 V
Conversion AC to DC
Alternative Models Two Others

About the 86475-10R

General Product Series Information

The 86475-10R model is one of many rectifier stacks from Reliance Electric. We here at AX Control continue to supply the 86475-10R rectifier stack, as well as all of the other Reliance Electric rectifier stacks, despite the fact that they have since been deemed a discontinued product by Reliance Electric. We understand that many facilities still need rectifier stacks like this one, so please give us a call if that is your situation. We can tell you if we have it in stock and help you in placing your order.

Hardware Tips and Specifications

This 86475-10R Rectifier Stack device here is well-contextualized within a wealth of original Reliance Electric printed instructional manual materials on the internet, which means that the various hardware components and elements afforded to its normal assembly can be exposed on a part-by-part basis here:

  • The 86475-10R rectifier stack is rated as having 230 Volts of electric potential.
  • This rectifier stack is ideally used within drive systems that have variable speed capabilities, such as the MaxPak Plus and the FlexPak Plus drive systems.
  •  The 86475-10R rectifier stack was designed to take AC current and convert it to DC current. This is so that the power will flow in one direction, making it easier to manage than AC current.
  • One of the central components of the 86475-10R rectifier stack that helps this process is the gate coupling board that is located at the top of the device.
  • The gate coupling board is populated with many different electrical components, including a transformer, resistors, capacitors, diodes, terminal pins, and several wires.

AX Control has many versions of these gate coupling boards listed on our website, so be sure to check those out if you are in need of them. Some versions that we have include the 0-51378-15 and the 0-51378-19 models. This 86475-10R Rectifier Stack device is also guaranteed warrantied protection upon any original purchase here.

Frequently Asked Questions about 86475-10R

Is this 86475-10R Rectifier Stack a revised product?

Yes. The trailing R digit on the 86475-10R Rectifier Stack product number seems to indicate a revised product version.

Would this 86475-10R Rectifier Stack device be protected by any warranty upon my purchase here?

Yes. As with many Reliance Electric products, this 86475-10R Rectifier Stack would be protected by at least one year of warrantied protection upon your original purchase through this specific site.

Reviews For 86475-10R

Internal Review
(5.0)

This 86475-10R Rectifier Stack product offering is a somewhat-fragile Reliance Electric product offering, given the fact that it exists with a stack-style assembly with numerous components presenting various snap risks. This 86475-10R Rectifier Stack product here would most likley be protected by a singular year of warrantied protection upon a purchase here. This 86475-10R Rectifier Stack is a small and light Reliance Electric new or reconditioned product, and is available here with both repair and replacement opportunities for you. - AX Control Lead Technician
