Shark XL Processor Module

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a 45C900 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 45C900
  • SKU: 45C900RE
  • Manufacturer: Reliance Electric
  • Series: Shark XL

45C900 Technical Specifications

Manufacturer Reliance Electric
Series Shark XL
Part Number 45C900

Product Description

The 45C900 is a Shark XL Series Processor made by Reliance Electric. There is a possibility that Baldor Reliance and ABB also sold this processor. This module is a part of the Reliance legacy series and maybe a little hard to find. Please refer to AX Control for the availability of the 45C900.

The 45C900 is a processor module that does not have the memory module option. There are two memory modules that can be separately purchased to allows for customization of the processor card. These memory modules are the 45C977 or the 45C975. The 45C977 grants the processor EEPROM memory with 2K words. The 45C975 memory module is EEPROM memory with 1K words. This is a non-volatile memory that is without batteries. This card has the following power requirements: 24VDC and 115/230 VAC at 50/60 Hz.

The 45C900 has two LED indicators on its faceplate. They are labeled power and run. There is also a connector on the faceplate. This processor does not come in a protective chassis or enclosure.  This module should only be used in an environment that has a humidity range of 20-90% non-condensing and a temperature range between 0 to +55% Celsius.

The 45C900 can be mounted to a Shark XL series card rack that has anywhere from 3-9 slots. Using a rack with more card slots will allow for future system expansion. The processor will consume only one of the slots on the rack. The power supply that can be selected for this rack set up does not take up a slot on the rack.

Frequently Asked Questions about 45C900

What is the size of a Reliance Shark XL 45C900?
45C900 is 6 inches high, 45C900 is 1.4 inches wide, and 45C900 is 4.6 inches in depth. The shipping weight of a 45C900 is 7 ounces.
What is the program execution speed on a Reliance 45C900?
The program execution speed on a 45C900 is 5 micro-seconds per standard instruction the 45C900 receives.
How many internal outputs are on a 45C900?
There are 256 non-retentive internal outputs on a 45C900 and 256 retentive internal outputs on a 45C900
How many external I/O's are on a Reliance Shark XL 45C900?
There are 160 external I/O's on a 45C900
What is the maximum remote I/O distance on a 45C900?
The maximum remote I/O distance is 1,000 feet on a 45C900
Where can I find a manual on 45C900?
We can send you a link to the Reliance Electric Shark XL Series II Manual where you will find a lot about the 45C900. The manual goes describes 45C900 and the manual identifies features on a 45C900

Repair Services For 45C900

Type Lead Time Price Action
Repair Service 1-2 weeks $774

Our highly skilled technicians can repair your 45C900. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
