8005-EPS-50

About the 8005-EPS-50

The 8005-CB-60 is an I/O Expansion Cable made by Square-D. This cable is no longer being supported by the original manufacturer and may be a little hard to find. AX Control attempts to keep this cable in stock though.

This is a 1-meter I/O expansion cable created for a SY/MAX Class 8005 Series A-2 I/O module. This cable is typically used when there is limited space for installation. It can be used to expand the processor unit by a row or more. When installing the cable, do not use a wiring conduit. It is recommended that a specific mounting plate should be used. This cable has the capacity to extend the I/O expansion up to a distance of 5 meters (including the cable and the space for the modules).

It is possible that an expansion base will be needed to increase the installation space. Expansion bases can be connected together using the expansion cables. When installing the cable, it is important to bend the cable so that it meets the base side, it should not be bent so the cable is facing upwards. These expansion cables are specifically keyed so that they are the only cable that can be plugged into their specific sockets.  One end of the cable plugs into the expansion base unit and the other end plugs into the expansion power supply unit. The connector cover is attached to the expansion power supply unit and will help secure the cable. To connect the connector cover: connect the cable, invert the connector cover legs, push the connector cover into the power supply slot.
