8030-RIM-361

About the 8030-RIM-361

The 8030-RIM-361 is a 16 Function 240 VAC/DC Input Module manufactured by Symax. The module uses an optical type of isolation. The isolation rating is the 2500 V RMS. The operating voltage range is 180-264 VAC (50/60 Hz) or VDC. The input current draw is 3.75 mA at 180V and 5.5 mA at 264v. The must turn ON voltage 180V. The must turn ON current is 3.75 mA (at 180 V). The must turn OFF voltage is 60 V. The must turn OFF current is 1.25 mA (at 60 V). The input impedance is 48K OHMS resistive. The turn on and turn off time is 8 ms Nominal. The rated current draw on Sy/Max power supply is 300 mA at 100% duty cycle. The ambient temperature rating is zero degrees Celsius to sixty degrees Celsius, with a non-condensing humidity rating of five to ninety-five percent. The inputs for the module are as follows. Input 1 (01), Input 2 (02), Input 3 (03), Input 4 (04), L2 (1A), Input 5 (05), Input 6 (06), Input 7 (07), Input 8 (08), L2 (2A), Input 9 (09), Input 10 (10), Input 11 (11), Input 12 (12), L2 (3A), Input 13 (13), Input 14 (14), Input 15 (15), Input 16 (16), and L2 (4A). There are sixteen red lights at the top of the module that corresponds with the sixteen inputs, to indicate if there is a problem. If you would like more information, please refer to the instruction manuals produced by Symax.

Please call AX Control if you’d like a quote.
