About the 8030-ROM-871
The 8030-ROM-871 is a 64 Function Reed Relay (Form A) Output Module. There are eight outputs per common. The module uses a relay type of isolation. The isolation rating is 1400 V RMS. The turn on and turn off time is 1.5 ms Nominal. The module uses a Wickman 19374K, TR5-T fuses. There is a red LED that will illuminate when it receives an ON signal from the processor. The voltage range for this module is five to thirty VAC/VDC. The current maximum is 400 mA/output and 2.5 A/common. The maximum surge current is 0.5A. The maximum power rating (switching) is 8VA (AC) 8 Watt DC. The initial relay contact resistance is 150 milliohms. The relay contact life for this module are 200 X 10,000,000 operations. The maximum reed relay operating frequency is 100Hz. The rated current draw on the Sy/Max Power Supply is 1250 mA at 100% duty cycle. The output module is labeled as follows. Output 1 (01), Output 2 (02), Output 3 (03), Output 4 (04), Output 5 (05), Output 6 (06), Output 7 (07), Output 8 (08), L1 (1A), Output 9 (09), Output 10 (10), Output 11 (11), Output 12 (12), Output 13 (13), Output 14 (14), Output 15 (15), Output 16 (16), L1 (2A), Output 17 (01), Output 18 (02), Output 19 (03), Output 20 (04), Output 21 (05), Output 22 (06), Output 23 (07), Output 24 (08), L1 (3A), Output 25 (09), Output 26 (10), Output 27 (11), Output 28 (12), Output 29 (13), Output 30 (14), Output 31 (15), Output 32 (16), L1 (4A), Output 33 (01), Output 34 (02), Output 35 (03), Output 36 (04), Output 37 (05), Output 38 (06), Output 39 (07), Output 40 (08), L1 (5A), Output 41 (09), Output 42 (10), Output 43 (11), Output 44 (12), Output 45 (13), Output 46 (14), Output 47 (15), Output 48 (16), L1 (6A), Output 49 (01), Output 50 (02), Output 51 (03), Output 52 (04), Output 53 (05), Output 54 (06), Output 55 (07), Output 56 (08), L1 (7A), Output 57 (09), Output 58 (10), Output 59 (11), Output 60 (12), Output 61 (13), Output 62 (14), Output 63 (15), Output 64 (16), and L1 (8A).
